DMQ 112-621.491
Description
Air Cooled motors from Kessler have been very successful in the industry for decades. As an asynchronous design, they are the most robust and cost effecttive solution for the main spindle drive. Due to the high field weakening, the compact design enables maximum speeds. It can be operated with small power units and does not require a surge protector. Especially for universal machines, the air cooled asynchronous motor offers the matching solution with an optimum cost-benefit ratio.
Additional information
| Weight | 122 lbs |
|---|---|
| Manufacturer | Kessler |
| Model # | DMQ 112-621.491 |
| Torque S1 | 73 |
| Torque S6 | 106 |
| Power S1 | 22 |
| Power S6 | 32 |
| RPM | 12000 |
| Motor Type | asynchronous |
| Tool Interface | Cylinder shaft |
| Release Unit | NO |
| Cooling | air |
| Bearing Lubrication | lubricated with grease |
| Control | Siemens/Fanuc/Heidenhain |
| Temperature Sensor | NO |
| Vibration Sensor | NO |
| Cooling Jacket | NO |
| Leakage Monitoring | NO |
| Temperature Compensation | NO |
| Retaining Clamping Set | NO |
| Minimum Quantity Lubrication | NO |
| Control of Surface Contact | NO |
| Rotary Union | NO |
| Clamp | NO |
